Brand: USER
Display screen size: 640*1920mm
Display screen resolution:344*1032
Overall dimensions: 640*2030*50mm
Base size：640*100*475mm
Overall weight of the machine: 50kg
Refresh: ≥3840HZ
Screen brightness: 550-800cd/m2
Product Introduction
FOLDABLE LED FPOSTER DISPLAY
Folding poster screens, as an innovative product that combines flexible display technology and portable design, have shown wide application potential in multiple fields due to their foldable,lightweight, high-resolution and other characteristics.
Silent universal wheel：The base is equipped with 4 universalwheels, making it easy to move thedevice at any time.
Complete interfaces：Easy to connect and transfer, such as WFlnetwork interface USB, Audio output, etc.
Silent universal wheel：Quickly dissipate heat and maintainhigh performance at low temperaturesfor a long time.
| Display Specification | |||||||||
| Module size | 320*160mm | ||||||||
| Pixel pitch | 1.25mm | 1.53mm | 1.86mm | 2mm | 2.5mm | ||||
| Display area | 640*1920mm | ||||||||
| Resolution | 512*1536 | 416*1248 | 344*1032 | 320*960 | 256*768 | ||||
| Performance Parameters | |||||||||
| Brightness | 400-700cd/m2 | ||||||||
| Refresh rate | 3840HZ | ||||||||
| Viewing angle | 140°/140° | ||||||||
| Contrast ratio | 5000∶1 | ||||||||
| Gray Scale (Bit) | 14bit | ||||||||
| Color temperature | 3200-12000 adjustable | ||||||||
| Controller | Novastar US20 | ||||||||
| storage | DDR3 SDRAM 1GB | ||||||||
| Flash memory capacity | 32GB | ||||||||
| Usage Parameters | |||||||||
| Quantities of LED posters that can be combined to form one screen | 2 | 4 | 6 | 6 | 7 | ||||
| Input Voltage | AC110~240V,47~63Hz | ||||||||
| IP rating(Front/Rear) | IP45 | ||||||||
| Lifespan | ≥100,000 hours | ||||||||
| Maximum power consumption | <=800W | ||||||||
| Average power consumption | <=240W | ||||||||
| Temperature-operating | -20℃– 70℃ | ||||||||
| Humidity-operating | 10%-95%RH | ||||||||
| Control way | USB /Phone/iPad/PC | ||||||||
| Maintenance method | front maintenance | ||||||||
| Physical Dimensions | |||||||||
| Weight | 45KG (excluding packaging) | ||||||||
| Overall dimensions | 640mm (W) × 1982mm (H) (including base height) × 80mm (T) (including frame) | ||||||||
| Base size | 635mm(L)×62mm(H)×450mm(W) | ||||||||
| Cabinet material | die-casting aluminum | ||||||||
